Manufacturer Part Number | W4E420-CU03-36 |
Manufacturer | ebm-papst Inc. |
Description | FAN AXIAL |
Manufacturer Part Number | W4E420CU0336 |
Series | W4E420 |
Part Status | Active |
Voltage - Rated | 230VAC |
Size / Dimension | Round - 544mm Dia |
Width | 142.0mm |
Air Flow | - |
Static Pressure | 0.401 in H2O (100.0 Pa) |
Bearing Type | Ball |
Fan Type | Tubeaxial |
Features | Capacitor, Thermal Overload Protector (TOP) |
Noise | - |
Power (Watts) | 385W |
RPM | 1520 RPM |
Termination | 4 Wire Leads with Splice Terminals |
Ingress Protection | IP54 - Dust Protected, Water Resistant |
Operating Temperature | -13 ~ 131~F (-25 ~ 55~C) |
Approvals | CE, CSA, EAC, UL |
Weight | - |
