Manufacturer Part Number | W4D400-DP12-40 |
Manufacturer | ebm-papst Inc. |
Description | FAN AXIAL |
Manufacturer Part Number | W4D400DP1240 |
Series | W4D400 |
Part Status | Active |
Voltage - Rated | 230VAC |
Size / Dimension | Square - 540mm L x 540mm H |
Width | 152.0mm |
Air Flow | 1528.5 CFM (42.80m3/min) |
Static Pressure | 0.502 in H2O (125.0 Pa) |
Bearing Type | Ball |
Fan Type | Tubeaxial, 3 Phase |
Features | Dual Voltage, Thermal Overload Protector (TOP) |
Noise | - |
Power (Watts) | 225W |
RPM | 1640 RPM |
Termination | 9 Wire Leads with Splice Terminals |
Ingress Protection | IP44 |
Operating Temperature | -40 ~ 140~F (-40 ~ 60~C) |
Approvals | CCC, CE, CSA, UL |
Weight | - |
