| Manufacturer Part Number | R3G225-RE07-03 |
| Manufacturer | ebm-papst Inc. |
| Description | 225 MM EC CENTRIFUGAL FAN |
| Manufacturer Part Number | R3G225RE0703 |
| Series | Green Tech RadiCal? R3G225RE |
| Part Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Round - 225mm Dia |
| Width | 99.00mm |
| Air Flow | 765.2 CFM (21.43m3/min) |
| Static Pressure | - |
| Bearing Type | Ball |
| Fan Type | Motorized Impellers |
| Features | Electronic Commutation (EC) |
| Noise | 70.0 dB(A) |
| Power (Watts) | 170W |
| RPM | 2860 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection | IP54 - Dust Protected, Water Resistant |
| Operating Temperature | -13 ~ 140～F (-25 ~ 60～C) |
| Approvals | UL |
| Weight | 3.9 lbs (1.8kg) |
