Manufacturer Part Number | R3G190-RD45-03 |
Manufacturer | ebm-papst Inc. |
Description | 190 MM EC CENTRIFUGAL FAN |
Manufacturer Part Number | R3G190RD4503 |
Series | Green Tech RadiCal? R3G190RD |
Part Status | Active |
Voltage - Rated | 230VAC |
Size / Dimension | Round - 190mm Dia |
Width | 90.70mm |
Air Flow | 573.9 CFM (16.07m3/min) |
Static Pressure | - |
Bearing Type | Ball |
Fan Type | Motorized Impellers |
Features | Electronic Commutation (EC) |
Noise | 72.0 dB(A) |
Power (Watts) | 169W |
RPM | 4120 RPM |
Termination | 2 Wire Leads |
Ingress Protection | IP54 - Dust Protected, Water Resistant |
Operating Temperature | -13 ~ 140~F (-25 ~ 60~C) |
Approvals | UL |
Weight | 3 lbs (1.4kg) |
