ABB Bailey NFAN01 FAN ASSEMBLY MODULE

The NIMF01 Multi-Function Controller Termination Moduleterminates two RS-232-C ports for the IMMFC03 Multi-Function Controller, INICT01 INFI-NET to Computer Transfer Module, INPPT01 Plant Loop to Plant Loop Transfer Module and INPCT01 Plant Loop to Computer Transfer Module. When terminating an IMMFC03 module, it enables the IMMFC03 module to communicate to a computer, terminal, printer orsequential events recorder through the serial ports (see Figure1-1). It also provides a serial link for a NDCS03 Digital ControlStation or IISAC01 Analog Control Station through a NICS01Control I/O Termination Module. The IMMFC04 and IMMFC05Multi-Function Controllers).
